TH400 Rebuild Kit

031901HPPWRSK
Alto Red Eagle Turbo Hydromatic 400 Complete Rebuild Kit With Power Packs
Pricing: $299.00

Qty:

Description

This Kit Includes The Following:

  • New vacuum modulator
  • New high performance intermediate band
  • New thrust washer Kit
  • New bushing kit
  • New filter
  • New teflon seals
  • New gasket and seal kit
  • High performance Alto Red Eagle Power packs
  • High performance Kolene Steels

This new TH400 rebuild kit comes with everything needed for your standard High Performace clutch and steel refresh for your TH400 with Alto Red Eagle clutches and Kolene Steels.

Alto Red Eagle® material offers similar mid-point coefficient at high horsepower applications. In addition, the Alto Red Eagle® material gives superior friction wear characteristics at high energy engagements. The leading competitor's material degrades thermally and physically after reaching approximately 2.25 HP/in2.

Below we offer some engineering data collected with this particular clutch.

Six Level High Energy Test
On Frictional Properties And Wear

Lbs./Sq. Inch Pressure Required To Stop Flywheel In One Second

Levels Cycles OEM Manufacturer A
Pressure Required (Lbs./Sq.In.)
OEM Manufacturer B
Pressure Required (Lbs./Sq.In.)
ALTO Red Eagle
Pressure Required (Lbs./Sq. In.)
1 10 64 70 66
1 100 65 71 65
2 10 72 84 74
2 100 73 84 74
3 10 85 96 86
3 100 92 101 93
4 10 102 116 104
4 100 110 122 108
5 10 118 133 117
5 100 124 135 118
6 10 136 148 131
6 100 143 152 134

NOTE: The Lower Lbs./Sq.In. Required to stop the flywheel, the higher the frictional properties.

Results: Pressure required to stop the flywheel on "ALTO RED EAGLE" are slightly lower than "Manufacturer A" and well below "Manufacturer B."

Conclusion: The frictional properties of "ALTO RED EAGLE" are slightly higher than "Manufacturer A" and well above "Manufacturer B."



LEVELS INERTIA (lb.-ft.2) KINETIC ENERGY (lb.-ft.)
1 .261 30,232
2 .302 35,048
3 .344 39,865
4 .385 44,681
5 .426 49,498
6 .510 59,131

Test Schedule and Duration:
Test conducted in six energy levels. Each level consists of 100 clutch engagements at 60 second intervals, from 4600 RPM with a clutch lockup time of one second, the indicated pressure required to stop the flywheel in one second.

Details

  • 031901HPPWRSK
  • 031901HPPWRSK
  • 031901HPPWRSK
  • New

Shipping Information

  • Item Requires Shipping
  • 10.0 lbs.
  • W10.0000” x H12.0000” x L8.0000”
