SUNCOAST CATEGORY 1 6R140 TORQUE CONVERTER

SUNCOAST CATEGORY 1 6R140 TORQUE CONVERTER

(0) Reviews: Write first review
6R140-CAT1
SUNCOAST CATEGORY 1 6R140 TORQUE CONVERTER
Pricing: $2,695.00

Customize Your Item

- PLEASE SELECT -
 * required
- --Please Select-- -
Refundable Core Charge: $750.00
Qty:

Description

FEATURES AND BENEFITS:

  • Furnace-brazed fin construction for improved strength and reliability
  • Utilization of factory damper assembly ensuring refined lock-up strategies
  • New Torque Converter Clutch
  • Custom turbine and pump angle manipulation to customers' needs
  • SunCoast-custom rigid backing plate reduces deflection, improving apply conformity
  • Provides a more durable reaction surface than OE, improving longevity
  • New Torrington thrust bearing construction
  • Precision-balanced dynamically to exact tolerances
  • Billet Cover
  • Manufactured and Tested by American workers in Fort Walton Beach, Florida

The Ford 6R140 platform was designed and built in-house by Ford Motor Company. With a deep first gear (3.97:1), double overdrive, and a one-piece deep skirt case it is easy to see why the 6R140 transmission is such a workhorse.

Ford, when designing the 6R140, also added Sinter-brazed gear carriers and a dual media filter that can extend service intervals up to 150,000 miles.

The 6R140 Transmission also has an integrated live PTO with a higher torque capacity than its Allison counterpart, while coming in at a stealthy 25lbs lighter, as well.

Captive clutch failure in the Ford 6R140 is a chronic problem that is difficult to address with stock components or traditional methods.

Unlike most lockup converters, the 6R140 clutch does not engage the front cover — it moves away from the engine block and engages a stamped, steel backing plate, which is relatively thin and prone to flex. SunCoast addresses these issues by using a custom rigid backing plate that reduces deflection, improving apply conformity. This process provides a more durable reaction surface than OE, improving longevity and reliability for years to come.

Another weak point is the OE clutch, which is held together by a set of small, weak leaf springs. These springs are often broken or on the verge of breaking, causing the OE steel clutch plates to break loose and gouge the cover splines. Clutch failure occurs when damage and debris become severe, a particularly frequent issue in heavy-duty trucks that put massive stress on converter components.

This new 6R140 torque converter is a perfect replacement for customers who do a lot of heavy towing or work out of their vehicles and put reliability as a priority.

Details

Categories

Shipping Information

  • Item Requires Shipping
  • 78.0 lbs.
  • W15.0000” x H14.5000” x L12.2500”
