618 BILLET SFI APPROVED FLEXPLATE

618-BFP
Pricing: $535.00

Customize Your Item

- --Please Select-- -
Qty:

Description

618 BILLET SFI APPROVED FLEXPLATE

The Sun Coast 618-BFP Billet Flex Plate for your 1994-2007 Dodge 5.9L Cummins is a must have when it comes to putting power to the ground in your truck. The high torque of your Cummins in conjunction with a better designed torque converter can transfer the torque with no slip. The flex plate is bolted to the crank shaft, then the converter is bolted to flex plate. The torque from your Cummins is transferred to the flex plate, from the flex plate to the torque converter then to your input shaft in the trans. With increased torque from the engine and no slip out of the converter it can crack and/or rip the center out of a stock flex plate.

The Sun Coast billet flywheels are CNC machined from a forging for strength and reliefs are machined out between the converter mounting area and the crank flange to enable some flex. We designed our flexible billet flywheel with the understanding that it needs to flex but at the same time we added extra thickness to prevent cracking. We started with a better quality material and a better manufacturing process to make it stronger. Our flexible flywheel made or exceeded all the SFI specification 29.3 requirements for materials, mechanical properties, design and rotational integrity.


Features

  • Billet Construction
  • Replaces Factory Flex Plate
  • Exceed 29.3 SFI Specifications
  • NOTE: A SFI certified flywheel flex plate is required on drag racing vehicles running 11.99 and quicker in the 1/4 mile and 7.49 and quicker in the 1/8 mile, or any vehicle exceeding 135mph. It was changed in 2008 from the 29.1 SFI specification to the SFI specification 29.3 for automatic transmission flex plates for diesel applications. The new rules for the flexplate requires that the material can not be a stamped metal as many OEM and aftermarket flex plates are. To maintain the SFI specification 29.3 requirements, the flex plate must be replaced every three years.


Note: This will not fit a 93 or older torque converter.

Details

Categories

Shipping Information

  • Item Requires Shipping
  • 14.0 lbs.
  • W16.0000” x H4.0000” x L16.0000”
