SUNCOAST ALTO 4L60/65/70E REBUILD KIT

SC-057905HPPWRSK
SUNCOAST ALTO 4L60/65/70E REBUILD KIT
Pricing: $435.00

Qty:

Description

This 4L60E Rebuild kit Includes the Following:

  • NEW 4L60E OVERHAUL KIT
  • ALTO RED EAGLE CLUTCH KIT WITH POWERPACKS
  • HIGH PERFORMANCE KOLENE STEEL KIT
  • NEW 4L60E FILTER
  • NEW 4L60E BUSHING KIT
  • NEW 4L60E THRUST WASHER KIT

This is a complete 4L60E super rebuild kit containing Alto Red Eagle clutches with the 3/4 clutch pack that includes 8 clutches. This kit will include everything else you need to rebuild your 4L60E transmission. A new filter is included as well as a bushing kit and and thrust washer kit. The band in the kit is a high performance RedEagle band.

Alto Red Eagle® material offers similar mid-point coefficient at high horsepower applications. In addition, the Alto Red Eagle® material gives superior friction wear characteristics at high energy engagements. The leading competitor's material degrades thermally and physically after reaching approximately 2.25 HP/in2.

Below we offer some engineering data collected with this particular clutch.

Six Level High Energy Test
On Frictional Properties And Wear

Lbs./Sq. Inch Pressure Required To Stop Flywheel In One Second

Levels Cycles OEM Manufacturer A
Pressure Required (Lbs./Sq.In.)
OEM Manufacturer B
Pressure Required (Lbs./Sq.In.)
ALTO Red Eagle
Pressure Required (Lbs./Sq. In.)
1 10 64 70 66
1 100 65 71 65
2 10 72 84 74
2 100 73 84 74
3 10 85 96 86
3 100 92 101 93
4 10 102 116 104
4 100 110 122 108
5 10 118 133 117
5 100 124 135 118
6 10 136 148 131
6 100 143 152 134

NOTE: The Lower Lbs./Sq.In. Required to stop the flywheel, the higher the frictional properties.

Results: Pressure required to stop the flywheel on "ALTO RED EAGLE" are slightly lower than "Manufacturer A" and well below "Manufacturer B."

Conclusion: The frictional properties of "ALTO RED EAGLE" are slightly higher than "Manufacturer A" and well above "Manufacturer B."



LEVELS INERTIA (lb.-ft.2) KINETIC ENERGY (lb.-ft.)
1 .261 30,232
2 .302 35,048
3 .344 39,865
4 .385 44,681
5 .426 49,498
6 .510 59,131

Test Schedule and Duration:
Test conducted in six energy levels. Each level consists of 100 clutch engagements at 60 second intervals, from 4600 RPM with a clutch lockup time of one second, the indicated pressure required to stop the flywheel in one second.

Details

Shipping Information

  • Item Requires Shipping
  • 20.0 lbs.
  • W12.0000” x H12.0000” x L10.0000”
