GM 6L80, 6L80E Deep Transmission Pan (as cast)

6L80 Deep Transmission Pan
Pricing: $365.00



For GMC, Chevrolet, and Cadillac 1/2 ton trucks and SUVs, such as Silverado/Sierra 1500.

Pan includes magnetic drain plug and mounting hardware. Price varies with finish.

Volume: 2 quarts over stock

Number of Bolts: 18 (there are 20 holes, 2 holes locate the gasket and 18 holes for bolts to hold the pan to the transmission case)

Many 1/2 ton GMC and Chevy trucks and SUVs starting in 2009 have a 6 speed 6L80 transmission and can benefit from this PML transmission pan.


  • Extra capacity
  • Step to clear exhaust routed under rear of transmission pan (loosen pipe to install)
  • Fins and aluminum construction to dissipate heat from transmission fluid
  • Drain and magnetic drain plug for easier maintenance
  • Thick walls to add strength to the transmission housing
  • Thick gasket flange, machined flat, for a leak-free seal

The 6L90 pan is similar in shape but is longer at 18 1/2 inches and is found on 3/4 ton trucks and SUVs.




Shipping Information

  • Item Requires Shipping
  • 20.0 lbs.
  • W10.0000” x H10.0000” x L8.0000”
