68RFE 1700-1800 STALL 3D CONVERTER

68RFE-38-3D
Pricing: $1,825.00

Customize Your Item

- --Please Select-- -
Refundable Core Charge: $750.00
Qty:

Description

Features and Benefits
  •  3-YEAR, UNLIMITED MILEAGE WARRANTY
  •  CNC-Machined Billet Stator (1700-1800 Stall)
  •  Billet Lockup Apply Piston
  •  CNC-Machined Billet Steel Cover
  •  Balloon Plate
  •  4140 Turbine Splines
  •  4140 Hardened Hub
  •  3 Carbon-Graphitic Clutch Discs
  •  Furnaced-Brazed Fins
  •  Torrington Thrust Bearing Stator Design
  •  Pressurized Hot Soak Leak Testing
  •  Computer-Balanced to Within .01 Gram
  •  Precisioned-Assembled by Caring American Workers








This triple disc torque converter for the 2007-Current 68RFE equipped 6.7L Cummins is manufactured and assembled at SunCoast. Boasting more than 3.4x the lockup clutch surface apply area over stock (8.7inches vs. 29.7inches) and distributing the load over three separate surface apply areas, SunCoast's triple disc converters are sure to put all of the power to the ground. Starting with a solid chunk of steel, the cover is machined to exact specifications. Utilizing SunCoast's exclusive trapezoidal teeth design, the lockup portion of the converter is seamlessly integrated into the cover, eliminating a weak point and common source of chatter.

An upgraded billet lockup apply piston is able to transfer a much higher pressure to the lockup clutch without sacrificing durability. Instead of the factory-style plastic stator cap/thrust spacer, SunCoast utilizes a metal Torrington roller style bearing, which is better suited to take the heat, as well as wear and tear. The turbine assembly is TIG reinforced and heat-treated. This exponentially increases its lifespan under harsh conditions. Stall on this model is approximately 1800 RPMS, and much more efficient at energy transfer than the factory offering.

Details

Categories

Shipping Information

  • Item Requires Shipping
  • 77.0 lbs.
  • W14.0000” x H10.5000” x L14.0000”
