68RFE 1600-1700 STALL 3D CONVERTER

This triple disc torque converter for the 2007-Current 68RFE equipped 6.7L Cummins is manufactured and assembled at SunCoast. Boasting more than 3.4x the lockup clutch surface apply area over stock (8.7inches vs. 29.7inches) and distributing the load over three separate surface apply areas, SunCoast's triple disc converters are sure to put all of the power to the ground. Starting with a solid chunk of steel, the cover is machined to exact specifications. Utilizing SunCoast's exclusive trapezoidal teeth design, the lockup portion of the converter is seamlessly integrated into the cover, eliminating a weak point and common source of chatter.

An upgraded billet lockup apply piston is able to transfer a much higher pressure to the lockup clutch without sacrificing durability. Instead of the factory-style plastic stator cap/thrust spacer, SunCoast utilizes a metal Torrington roller style bearing, which is better suited to take the heat, as well as wear and tear. The turbine assembly is TIG reinforced and heat-treated. This exponentially increases its lifespan under harsh conditions. Stall on this model is approximately 1800 RPMS, and much more efficient at energy transfer than the factory offering.

This converter also comes with a billet stator that increases the effecincy of the converter dramatically. If you have a 68RFE that is used for "function" such as towing/hauling then this is exactly what you need. This converter stall speed is about 300 rpm's tighter than the factory unit and loads the turbos very nicely when unlocked in first, second and third giving you more power to the ground than the standard factory unit.
